| 型 号 | 额定风量 (m3/h) |
过滤器尺寸 W×L×H |
箱体外型尺寸 W×L×H/h |
风管法兰尺寸 | 吊顶开孔尺寸 | |
| 侧送风 | 顶送风 | A×B | W×L | |||
| ZY-320A | ZY-320B | 500 | 320×320×220 | 370×370×570/400 | 200×200 | 380×380 |
| ZY-484A | ZY-484B | 1000 | 484×484×220 | 534×534×570/400 | 320×200 | 544×544 |
| ZY-610A | ZY-610B | 610×610×150 | 660×660×550/400 | 320×250 | 670×670 | |
| ZY-726A | ZY-726B | 1500 | 726×484×220 | 776×534×570/400 | 400×200 | 786×544 |
| ZY-630A | ZY-630B | 630×630×220 | 680×680×620/400 | 320×250 | 690×690 | |
| ZY-915A | ZY-915B | 915×610×150 | 965×660×550/400 | 500×250 | 975×670 | |
| ZY-968A | ZY-968B | 2000 | 968×484×220 | 1018×534×570/400 | 500×200 | 1028×544 |
| ZY-1220A | ZY-1220B | 1220×610×150 | 1270×660×550/400 | 630×250 | 1280×670 | |
| ZY-945A | ZY-945B | 2200 | 945×630×220 | 995×680×620/400 | 500×250 | 1005×690 |
| ZY-1260A | ZY-1260B | 3000 | 1260×630×220 | 1310×680×620/400 | 630×250 | 1320×690 |
